10G Fiber Media Converter with SFP

Release time：2024-09-24 11:47viewed：times

10G Fiber media converter

Feature

u Support Jumbo Frame

u Transparent Transport and very low delay

u Support ITUT prescribed DWDM/CWDM wavelength

u Support DMI function for SFP+ fiber module

u Support Loopback test function

u Economic In-band Management function

u Powerful Network Management function(Web,SNMP,Console)

u Support hot plugging

u Support 2U Rack (16 channel) and standalone use

u Full State Led display

u Easy installation

u UTP cable length detection(only RJ45 interface)

APPLICATIONS

u Connection between fiber to copper 10Gbps Ethernet equipment function as fiber-to-copper media converter for long distance transmission

u Media converter for network backbone(SAN, LAN, MAN)

u Can be applied in Telecommunication room, R&D laboratory, Data center, and etc.

Performance Specifications

Performance Data	Technical Indexes
Transmission Speed	10Gb/s
Protocols	IEEE802.3an(10Gbase-T),IEEE802.3ae(10Gbase-SR/LR/ER/ZR)
Access Type	10G LAN
Interface Type	Type: RJ45 To/From SFP+
Transmission Distance	XFP/SFP+ module: Up to 80Km 10Gbase-T: 100meters Cat .6a cable
Maximum Packet Forwarding Rate	14,880,950/S
Network management information:	• Card type information • XFP/SFP+ fiber module detection • XFP/SFP+ fiber module DMI function(Temperature, Voltage, Optical power) • Link status detector • Enable/Disabled Loopback test function • UTP cable length detection ( only RJ45 interface ) • Remote card's status monitor ( only in pairs )
power requirement	Rack-mountable : AC 85 ~ 220V OR DC -48V Standalone: AC 220V OR DC -48V Power consumption: ≤9W
Work Environment	Operating Temp: 0~ 50 °C Storage Temp: -10~ 70 °C Humidity: 5%~90% ( non-condensing )
Dimension	Card: 11.5mm (W) × 78mm ( D) Standalone: 156mm ( W ) × 128mm ( D ) × 32mm ( H)
