1. Feature:
2. Application:
3. Absolute Maximum Ratings:
Parameter | Symbol | Minimum | Maximum | Units |
Storage Temperature | Tst | -40 | +85 | ℃ |
Supply Voltage | Vcc | 0 | +3.6 | V |
Operating Relative Humidity | RH | 5 | 95 | % |
Parameter | Symbol | Min | Typical | Max | Units | |
Supply Voltage | Vcc | 3.15 | 3.3 | 3.45 | V | |
Operating Case Temperature | Commercial | Tc | 0 | +70 | ℃ | |
Industrial | -40 | +85 | ||||
Power Dissipation | 1 | W | ||||
Data Rate | 155 | Mbps | ||||
5. Optical Characteristics:
(Ambient Operating Temperature 0℃ to +70℃, Vcc =3.3 V)
Parameter | Symbol | Min. | Typ. | Max. | Units |
Transmitter Section | |||||
Center Wavelength | lo | 1260 | 1310 | 1360 | nm |
Spectral Width(RMS) | Dl | - | - | 4 | nm |
Average Output Power | Po | -15 | - | -3 | dBm |
Extinction Ratio | Er | 12 | - | 18 | dB |
Rise/Fall Time(20%~80%) | Tr/Tf | 0.26 | ns | ||
Total jitter | Tj | 0.43 | UI | ||
Optical Eye Diagram | IEEE 802.3u and ANSI Fibre Channel Compatible | ||||
Receiver Section | |||||
Center Wavelength | lo | 1260 | 1620 | nm | |
Receiver Sensitivity | Rsen | -34 | dBm | ||
Receiver Overload | Rov | -3 | dBm | ||
Return Loss | 12 | dB | |||
LOS Assert | LOSA | -45 | dBm | ||
LOS Dessert | LOSD | -34 | dBm | ||
LOS Hysteresis | 0.5 | 5 | |||
6. Ordering information :
A-D0303-L3320C | Commercial | 0~70℃ |
A-D0303-L3320C | Industrial | -40~85℃ |
